Upgrade Your RV’s Propane Furnace With Electric Heat With The CheapHeat Add-On

We all know that traveling in an RV is a fantastic way to explore the world around us while continuing to enjoy the comforts of home on the road. Many of us enjoy traveling in all seasons, and one challenge RVers may face is staying warm during the colder months. We’ve written about several options to address this, including diesel heaters and small propane heaters, and answered the question “Can you use a propane heater indoors?”

However, in this post, we’re examining something entirely different: how to convert an RV furnace to electric using the RV Comfort Systems CheapHeat Add-On System. This cost-effective solution helps you stay warm and cozy in your RV, regardless of the season. But what are CheapHeat hybrid RV heaters, and how do they work? Are they safe? Do they save money over time?

Let’s explore the benefits and features of the CheapHeat system and how it can improve your RV heating experience.

What Is the CheapHeat Add-On System?

Most RVs come equipped with standard electric or gas furnaces, which can be effective but also have limitations, such as high fuel consumption, uneven heating, or inadequate insulation. The RV Comfort Systems CheapHeat Add-On System is designed to address these limitations and provide an affordable, efficient heating solution for RVs.

The CheapHeat system is essentially an add-on module that enables you to run your furnace like it was a big space heater, using 120V AC power from the shore connection (or your generator) to heat your rig instead of propane. This is an electrical heating option that works as an add-on assembly to your RV’s existing propane-fueled furnace, allowing you to choose between propane or electricity to heat your rig.

The CheapHeat unit is mounted directly downstream of the existing gas furnace and utilizes tungsten heating coils (with a replaceable fusible link) powered by 120V or 240V AC power to provide heat. A 12-volt fan motor on the furnace pushes the heated air through the ducts in the RV. In addition to the heating coil, it also uses a solid-state controller to communicate with the existing wall thermostat and the fan motor. All you need to do is select “Electric” or “Gas” on a new, dedicated wall switch, depending on which source you want to use (propane or electric) to run your furnace.

The controller works with both 30-amp and 50-amp shore power, using all the functions of your existing propane furnace with the added electrical heating coil assembly.

Let’s take a look at some key features and benefits of this system:

Versatile

One of the main advantages of CheapHeat is versatility. It can be installed alongside your existing propane furnace or electric heating system, giving you multiple options for heating your RV. This allows you to choose the most cost-effective and efficient heating source for any situation, be it propane, electric, or a combination of both.

Energy Efficient

The CheapHeat system uses electricity to generate heat, which can be more cost-effective than propane in some cases (think nightly or weekly RV park stays, where power is included in the rate). This can result in long-term savings, making it a worthwhile investment for RVers who frequently travel in colder climates. Considering the limited storage space on many RVs, having a built-in electric heating system is more space-efficient than keeping portable electric space heaters on board.

While burning propane for heat is generally about 60% efficient (with a significant amount of waste heat being exhausted outside the RV), RV Comfort Systems claims that their electrical heat source is 100% efficient, as the heating core is mounted in the direct flow of the distribution system. That means all the heat produced is forced through the ducts (for more information on propane furnaces, see our post “How Does a Propane Furnace Work?“).

Reasonably Easy to Install

Installing the CheapHeat system is fairly straightforward and can be done by a handy RV owner or competent DIY personnel. The system comes with detailed installation instructions (shown here). There are also RV service facilities that can install the system with a qualified RV technician at the helm.

This video shows the CheapHeat installation process:

Zone Heating

With the CheapHeat system, you can take advantage of your RV’s existing zoned heating (if applicable) to heat specific zones in your RV, allowing you to focus warmth on the areas where you need it most. This saves energy and ensures that you’re not overheating areas of your RV that don’t need as much heat.

Remote Control

CheapHeat includes a remote control that allows you to adjust the temperature and heat settings, making it easy to maintain a consistent, comfortable temperature throughout your rig as needed.

No Low-Temp Limits

The CheapHeat system doesn’t have the low-temp limits that heat pumps do because it doesn’t rely on extracting heat from the ambient (outside) air. That means you can still use it when it gets too cold for your heat pumps.

Furnace Blower Works Less

Tests show that CheapHeat heats an RV in less time than propane, so the furnace blower assembly works less to heat the same space. That’s partly because propane RV furnaces require pre- and post-purge cycling of the blower assembly to remove unburned propane and other gases from the sealed combustion chamber. If you’ve ever wondered why your propane furnace has periods of blowing cold air, it’s due to the fact that for every heating cycle, there are about 2 1/2 minutes of runtime with no flame or heat being produced. When switched to electric mode, the fan motor only operates when heat is being produced.

Configurable

The system can be configured to three different wattage ratings – 1,800, 3,750, and 5,000 watts, depending on the shoreline power limitations.

Freeze Protection

If your RV is equipped with a furnace duct to the basement and/or the enclosed water compartment, using the CheapHeat module means that you are also able to keep your basement warm and prevent your water lines from freezing. This is a benefit above and beyond using space heaters, which will keep YOU warm inside but won’t provide any heat to your RV’s basement.

What’s the Downside of Using CheapHeat to Convert an RV Furnace to Electric?

If you mostly boondock (even in cold weather), installing the CheapHeat Add-On may not be worthwhile for you. Sure, you could use your generator to run the electric heat, but you’d still be burning fuel to do that.

Boondocking aside, the real beauty of the CheapHeat system lies in its functionality for RVers who are connected to shore power. But this is also where there’s a downside. Using your furnace in electric mode means you’ll need to worry about exceeding your shore power capabilities. Otherwise, you may constantly be tripping the circuit breaker. This means when you’re running the furnace in electric mode, you may need to force your RV refrigerator and water heater to run on propane so you don’t pop the breaker at the pedestal.

As a result, RV Comfort Systems suggests that RVers not use other power-hungry appliances and devices while running the furnace in electric mode (at least not on a single 30-amp circuit). However, this is no different from managing other large power-draw items when connected to anything less than a 50-amp connection.

Is It Safe to Use the CheapHeat Add-On System to Convert an RV Furnace to Electric?

According to the manufacturer, the CheapHeat system is safer than using portable space heaters. To support this, they note that the coil assembly is safeguarded against failure by more than one method, making the permanently installed CheapHeat unit safe and reliable. They also note that the system’s safety is further enhanced by oversized components in the controller, a bi-metal safety switch wired into the coil assembly to protect it from overheating, and a replaceable fusible link that acts as a failsafe device for the common leg of the coils, acting like an in-line circuit breaker to protect against potential over-current or overheating situations.

Finally, the manufacturer notes that no carbon monoxide is produced using electric heat, making the CheapHeat system safer than gas heat in this regard. RV Comfort Systems notes that the only connection between the CheapHeat unit and the existing propane furnace is a simple wiretap on the fan motor conductor. According to CSA America (the RV Furnace certification group), this does not affect the ANSI certification of the gas furnace.

You can determine the correct model for your RV and how to ensure there’s room for it to be installed by reviewing their compatibility chart.

Have you installed a CheapHeat system in your RV? If you have, we’d love to hear about your experience. Please leave a comment below.
