Weight Distribution Hitch: Does My Trailer Need One?

If you tow anything behind your vehicle, especially if you’re towing a travel trailer, you may have considered using a weight distribution hitch. This post addresses the most common questions about a weight-distributing mechanism for a towing setup.

We’ll explain what a weight distribution hitch is, what it does, and how it impacts the towing experience and overall towing safety. Ultimately, we aim to help you determine whether or not you even need one.

Let’s dive right in!

What Is a Weight Distribution Hitch?

A weight distribution (or “WD”) hitch is a load-leveling hitch that allows your tow vehicle and travel trailer to work better together to give you a safer (and more pleasant) towing experience. It distributes the weight between the two vehicles more evenly to achieve a more level/balanced towing setup. This is why WD hitches are sometimes referred to as load-leveling hitches or load-equalizing hitches.

Essentially, a weight distribution hitch distributes the trailer tongue weight across all the wheels of your towing vehicle. Trailer tongue weight is the downward force that the tongue of a trailer applies to the hitch ball of the tow vehicle (you can learn more about tongue weight in our post entitled “What Is Tongue Weight And Why Is It Important?“).

A WD hitch’s job is to distribute the tongue weight more evenly over the entire towing vehicle rather than just on the rear axle. This allows the tow vehicle and the travel trailer to ride together in a more level, balanced manner. Properly distributing the weight to achieve a more level and balanced setup will give your tow vehicle more controlled steering and braking while keeping the trailer’s weight evenly distributed on its axles (and tires and brakes).

Not only does this give you a safer and more pleasant towing experience, but properly setting up a good weight-distributing hitch will also lessen the strain on your tow vehicle and your travel trailer.

How Does a Weight Distribution Hitch Work?

A typical WD hitch employs spring bars to distribute the tongue weight more evenly to the axles of the tow vehicle and travel trailer, making both vehicles more level/parallel with the road. The hitch on your tow vehicle connects to the travel trailer using a hitch ball (sometimes called a trailer ball). It’s easy to picture what happens when you lower a heavy trailer coupler onto it — the weight pushes it & the rear of the towing vehicle downward.

A large travel trailer can easily have a tongue weight of 1,000 lbs or more. So, placing that weight down onto the hitch ball can (and will) push the back of the towing vehicle downward — sometimes by quite a bit. This reduces weight on the front axle of the towing vehicle, reducing traction and steering control. And, of course, that means that the front of the trailer is now lower as a result.

On multi-axle trailers, this also shifts weight onto the front axle, potentially overloading its tires, brakes, and suspension components. All in all, a bad situation.

But a weight distribution hitch uses components like spring bars, with one end attached to the frame of the trailer, and the other end attached near the tow vehicle’s receiver. When connected, the spring bars are under tension and force the towing vehicle and travel trailer frame more in line with each other, reducing or eliminating the sag that tongue weight causes.

So, the spring bars provide tension that applies an opposing force (lifting up) to the downward pressure of the travel trailer’s tongue weight. This achieves the goal of making the tow vehicle and travel trailer more level and stable.

Here’s a video explaining how it all works:

Does a Weight Distribution Hitch Reduce Sway?

Weight distribution and sway control go hand-in-hand, so a weight distribution hitch will help reduce sway.

For example (as we noted in our recent post addressing the question “What Is a Fifth Wheel?“) towing a fifth wheel provides better handling and control than towing a travel trailer. Much of this is because a 5th wheel’s weight is placed directly over the truck’s rear axle. This helps significantly with balance and sway prevention.

So, anything that helps with balance and weight distribution across the system will reduce sway. (See our post on stabilizing an RV for more on this concept.) By definition, then, properly redistributing the weight across the front and rear wheels of the tow vehicle will reduce sway that the improper distribution of weight would otherwise cause.

What’s the Difference Between Weight Distribution and Sway Control?

Note that while there are weight distribution hitches that offer built-in sway control, a sway control bar alone does not offer weight distribution. As you may recall from our posts on trailer sway control and trailer sway bars, many factors can contribute to trailer sway. These include wind, road conditions, tire pressure, speed, tongue weight, and the number of axles your trailer has.

But cargo weight distribution is one of the most significant causes of trailer sway. Moving more weight to the front can help reduce sway (as can driving slowly in areas with high wind conditions). We included this video in our post on trailer sway control to demonstrate the results of the redistribution of weight:

A sway control bar uses friction to keep your trailer centered as it rides behind your tow vehicle. So, if the rear of the trailer starts to sway, the friction/sway bar functions like a side-to-side brake, offering enough resistance to keep your trailer centered.

However, depending on the towing capacity of your tow vehicle and the weight of your travel trailer, sway can still occur even if you’re using a very good sway bar or anti-sway hitch. This is where the additional assistance of a weight distribution hitch comes into play, to better distribute the weight of the entire setup across the front and rear axles of your rig.

So, sway control and weight distribution are not the same thing. They do go hand-in-hand, but they’re not the same.

Does a Weight Distribution Hitch Allow Me to Tow More Weight?

The answer to this question is (sort of) yes and no, but the details are SUPER important. Some Class 3, 4, and 5 receiver hitches have two weight ratings. One is for when a weight distribution hitch is being used, and the other is for when no WD hitch is installed. In this case, it’s possible that the WD hitch can increase the approved weight rating by several hundred pounds.

However, a weight-distributing hitch DOESN’T increase the weight capacity of your tow vehicle or any other component of your towing system. For example, if your tow vehicle is rated to tow 8,000 pounds, and you install a WD hitch, your vehicle will still be rated to tow 8,000 pounds. And that means that even though a WD hitch helps to spread the tongue weight of the trailer to the front axle of the towing vehicle, it’s still adding weight… and you CANNOT exceed the GVWR.

Perhaps the most important thing to remember is that you should never exceed the weight rating of the lowest-rated component of your towing system, whether you have a weight distribution hitch installed or not.

Is a Weight Distribution Hitch the Answer to All My Towing Concerns?

Absolutely not. A weight-distributing hitch can be a band-aid solution to a deeper balance/leveling problem. Let’s talk about why your towing vehicle and travel trailer need to be level in the first place. (It’s all about balance!)

If your towing vehicle is sitting either nose-up or nose-down when attached to your travel trailer, this means the weight of the vehicle has shifted. This will impact the rig’s driving dynamics.

Other factors come into play when you’re also working to achieve a well-balanced towing setup. These include the weight rating of your tow vehicle, how long the vehicle is (wheelbase), proper payload distribution (vehicle and trailer), and correct tire pressures (both vehicle and trailer).

PRO TIP: RVgeeks subscribers have FREE access to our eBook — How To Inflate RV Tries Correctly — an important safety read. If you haven’t already done so, subscribe today to read it (and our daily RV newsletters).

Tow Vehicle Nose Up?

If you connect your tow vehicle and travel trailer and find that the tow vehicle is nose up, then you’ve got too much weight in the back of the tow vehicle (and/or on the hitch ball).

The problem is that with the front of the tow vehicle lifted, the grip of your front tires will be reduced, negatively impacting steering and braking. This is exactly what weight distribution hitches are for.

Tow Vehicle Nose Down?

If you hitch up your tow vehicle & travel trailer and find that your tow vehicle appears to have a nose-down position, the tow vehicle’s weight is too far forward. Or, more likely, the trailer is improperly loaded (with too much weight at the rear). This can also be caused by over-adjusting a weight distribution hitch (too much of a good thing?).

This nose-down posture on the towing vehicle also increases the potential for trailer sway.

While a weight-distribution hitch may solve your troubles, there are other ways to fix a truck or tow vehicle that’s squatting.

How Do I Know If I Need a Weight Distributing Hitch?

Unless you’re towing one of the smallest rigs (such as a teardrop trailer), most travel trailer owners will experience improvement by using a WD hitch. But without question, use a WD hitch if your travel trailer weighs 50% or more than your tow vehicle weighs.

A weight distribution hitch can help reduce trailer sway in high winds or when being passed by (or when passing) large vehicles. It will also help increase stability and reduce lane wandering.

A primary situation dictating the use of a weight-distributing hitch is if the rear of your tow vehicle sags. When this happens, your tow vehicle’s nose will be pushed upward, reducing front-wheel traction and steering control. It also reduces ground clearance at the rear of the vehicle.

And finally, if the manufacturer of your tow vehicle recommends or requires a WD hitch for certain trailer weights, you should never ignore this recommendation/requirement. The best way to check for these types of recommendations or requirements for your vehicle is to consult your owner’s manual.

Weight Distribution Hitches to Consider

Here are a few popular weight distribution hitches to consider, should you be in the market for one. Be sure to check (and double-check) all specs when ordering any WD hitch, to be sure it’s the best hitch for your particular tow vehicle and travel trailer setup.

Camco Eaz-Lift TR3 1,000lb Weight Distribution Hitch

The Eaz-Lift TR3 1,000 lb Kit is well-built weight distribution hitch. Contrary to the product name including the “1,000 lb” rating, it’s able to support up to a 1,200 lb. maximum tongue weight and up to a 12,000lb trailer weight.

The TR3 also features adjustable sway control through the use of a brake-pad-like friction plate that resists the rotation of the trailer behind the towing vehicle. By simply adjusting this clamp, you can decide how much sway control is exerted on the trailer (or turn the sway control completely off in dangerous or icy road conditions).

It includes a pre-installed 2 5/16-inch hitch ball and is easy to install on both top-mount couplers (most common) or bottom-mount/underslung coupler style trailers (like our Outdoors RV trailer).

We chose this exact hitch for use with our Outdoors RV 19MKS. We like it for a the following reasons:

1. It’s QUIET! Many of the hitches we’ve seen others using seem to make a LOT of clunking and clanking noise when maneuvering the trailer in a campground. The Eaz-Lift TR3 doesn’t have that issue and is much quieter than other hitches we’ve seen (though not COMPLETELY quiet).
2. It’s sleeker and more streamlined than other units and doesn’t look too bulky when installed and in use.
3. The brackets for holding the spring bars are easy to lever into place, making connecting and disconnecting the trailer an easy process.
4. The sway control uses a (replaceable) brake pad-style mechanism to add friction to the pivot point, making it a user-serviceable part that’s less expensive to maintain.
5. The sway control is adjustable, allowing you to add as much as is needed to control your trailer’s sway (or allowing you to completely disable it when in dangerous conditions like when traveling on icy roads).

The Eaz-Lift TR3 is available in several different capacities. You can choose:

• 400lb TR3 (600lb max tongue weight / 6,000lb max trailer weight)
• 600lb TR3 (800lb max tongue weight / 8,000lb max trailer weight)
• 800lb TR3 (1,000lb max tongue weight / 10,000lb max trailer weight)
• 1,000lb TR3 (1,200lb max tongue weight / 12,000lb max trailer weight)
• 1,200lb TR3 (1,500lb max tongue weight / 15,000lb max trailer weight)

All of the available models should be available from the following listing on Amazon:

ANDERSEN Weight Distribution Hitch

Made in the USA, this weight distribution hitch improves your towing experience by giving you a smoother ride and better control as it distributes the tongue weight of the trailer across the combination of the tow vehicle & travel trailer, leveling the load.

With forged steel spring bars, this WD hitch weighs just over 17 pounds and comes with an adjustable 2″ shank with a universal fit to any 2″ trailer hitch receiver.

This particular hitch has a 2 5/16″ trailer ball and 3″, 4″, 5″, and 6″ universal frame brackets, and comes with a money-back guarantee.

CURT 17601 TruTrack 2P Weight Distribution Hitch with 2X Sway Control

CURT TruTrack integrates the sway control function into the design of the hitch. The tilting head is easily adjustable without disassembly of the hitch, and the entire system is designed for easy setup and adjustment.

This WD hitch system weighs 94 pounds and features powerful round spring bars and an adjustable 7-hole shank that fits a 2″ receiver.

The hitch is rated for 8,000 to 10,000 pounds GTW (gross trailer weight) and 800 to 1,000 pounds tongue weight.

CURT’s TruTrack system levels the vehicle and trailer and reduces trailer sway.

One final note… there are some very high-end… and heavy… and expensive!… hitches in an entirely different category of their own, commonly known as Hensley-style hitches (made by Hensley Manufacturing and ProPride). These weight-distributing, sway-eliminating hitches are so specialized that we wrote a dedicated article about them: Do Hensley & ProPride Hitches Eliminate Trailer Sway? (the quick answer is “YES!”)

Do You Use a Weight Distribution Hitch?

Let us know your favorite WD hitch system and why you like it. Are there features that you’ve found that contribute to a safe and easy towing experience? Drop us a comment and let us know!

UPDATE! NEW TRAILER TOWING & WEIGHT LIMIT POST, VIDEO & CALCULATOR!

We’re excited to announce that we’ve released a new video and blog post all about Trailer Towing & Weight Limits. We’ve included a FREE towing and weight calculator that we designed to do all the math for you, making sure your rig is properly balanced and within all weight limits. Don’t let a sagging trailer alert everyone in the campground that you’re overweight, and don’t let the dreaded trailer sway ruin your trip (or worse)!
